Main Uses:
This machine is suitable for pharmaceutical, chemical and food industry, especially suitable for mixing all kinds of large-tonnage materials.

Working Principle:
Mixing tube and the cylindrical barrel, barrel without any stirring device, for rotation around its axis of symmetry the same time, around the horizontal axis to "be upside- down" swinging movement, forcing the barrel of the material has both spread mixed have a mobile mixed. The machine has a mixing time is short, mixed evenly, mix and high outpu

Model	Barrel Capacity	Loading capacity	Maximum charge capacity	Shake, turn times	Total motor power	Dimensions (L× W × H)	Barrel weight	Weight (kg)
EYH-60	60	30	20	50	0.4	700×730×1100(mm)	15	115
EYH-150	150	75	50	37	1.15	800×1050×1450(mm)	50	190
EYH-300	300	150	100	30	1.15	900×1350×1550(mm)	60	340
EYH-600	600	300	200	23.6	3	1170×1640×2050(mm)	140	1150
EYH-800	800	400	280	19.8	3	1320×1950×2150(mm)	200	1600
EYH-1000	1000	500	350	19.8	3	1360×2040×2300(mm)	240	1700
EYH-1500	1500	750	520	16.2	4.4	1580×2400×2550(mm)	320	2000
EYH-2000	2000	1000	700	16.2	7.4	1740×2600×2770(mm)	430	2600
EYH-3000	3000	1500	1050	13.8	11	1800×2900×2950(mm)	620	3500
EYH-4000	4000	2000	1400	12.8	13	1970×3300×3300(mm)	700	4100
EYH-6000	6000	3000	2100	11.2	18.5	2300×2900×3800(mm)	1100	6100
EYH-8000	8000	4000	2800	10.4	22	2540×4100×4050(mm)	1450	7900
EYH-10000	10000	5000	3500	9	30	2900×4500×4400(mm)	1650	9500
